Features
- Comply with Cat6 specifications
- 4-pair unshielded twisted pair (UTP) cable
- Pairs are braided in aluminum foil with drain wire
- 23 AWG solid copper conductor for superior conductivity
- HDPE insulation
- FR PVC Jacket
- Verified compliant with EIA/TIA standards by ETL
- UL-listed
- Packaged in an easy-to-pull box for easier installation
Specifications
- Category : 6 UTP Solid cable
- Conductor : Conductor : 23 AWG (Solid)
- Conductor Meta : Conductor Meta : Bare Copper
- Insulation Material : HD-PE
- OD : 6.1mm ±0.2
- Resistance Unbalance : 5% Max
- Capacitance Unbalance : 330pF/100m
- Delay Skew : <45nS
